PANALYTICAL X’PERT PRO X-RAY DIFFRACTOMETER

PANALYTICAL X’PERT PRO X-RAY DIFFRACTOMETER

PANALYTICAL PW3040 X-RAY DIFFRACTOMETER

Location

Electron Microscopy Lab (EM Lab) – Hill Hall

Contact

Xerxes Steirer – ksteirer@mines.edu

GET TRAINED ON THIS INSTRUMENT

Instrument Details

This PANalytical (nee Philips) instrument is equipped with a versatile computer-controlled diffractometer and is ideal for routine XRD analysis of powder/polycrystalline specimens. Collection and search software includes the current ICDD database.

  • Routine powder/polycrystalline diffraction
  • Computer Controlled Stage with X’pert Pro MPD
    • Data Collector and DataView Software
    • HighScore Search Software
    • Current ICDD Database
Specimen Prep Capabilities in the Electron Microscopy Lab

GENERAL

  • Slow Speed Diamond Saws
  • EVACTRON CombiClean Decontaminator

SEM

  • JEOL IB-0910CP Cross-Section Polisher
  • Hummer IV Sputtering System (Au/C Coater)

TEM

  • 3mm Foil Punch
  • South Bay Model 350 3mm TEM Disk Cutter
  • Gatan Model 600 Duo Mill Ar ion mill
  • Fischione Electropolishing System
